1970-1981 Firebird/Trans Am 2nd Gen F-Body
Pontiac V8 1970-1981 Firebird/Trans Am 2nd Gen F-Body
Order By Year — 1970-1981 Firebird/Trans Am 2nd Gen F-Body for Pontiac V8s
Parts for the 2nd Gen Firebird and Trans Am split by year more often than owners expect, and subframe connectors are the clearest example: 1970-73 and 1974-81 cars take different pieces. Check the build year before ordering anything for this chassis, not the decade.
Butler lists connectors covering both halves of the run, including a Butler Performance set that fits the whole 70-81 span, alongside the RideTech StreetGRIP, coil-over and air systems that belong on a chassis once it has been stiffened.
Browse 1970-1981 Firebird/Trans Am 2nd Gen F-Body Products
Popular Brands:
More About 1970-1981 Firebird/Trans Am 2nd Gen F-Body
1. Connectors, and which set is yours
A second-gen body flexes between the front subframe and the rear leaf spring mounts. Both sets below address that, and neither requires fabrication.
| Butler Performance 70-81 set | the PTFB connectors, covering the entire second-generation run in one part number. They can go on bolted or welded, arrive powder coated, and ship with solid body bushings offering standard height, a 1/2" drop or a wedged position. A good answer on T-top cars, where the roof is doing none of the structural work. |
| RideTech connectors | year-specific, one version for 1970-73 and another for 1974-81. Heavy rectangular steel tube, satin black finish, hardware in the box, and they play nicely with original leaf springs, with StreetGRIP composite leafs, and with RideTech's current 4-link. |
2. What goes on afterward
With the chassis tied together, the rest of the catalog for this car does what it claims.
| StreetGRIP | keeps the stock suspension architecture and upgrades every piece of it, including composite rear leaf springs and rebound-adjustable shocks. |
| Coil-over and air systems | both carry the TruTurn front package and the bolt-on rear 4-link, which between them take the vague steering and axle hop out of a second-gen. |
One ordering note that applies across all of it: RideTech sets front spring rates for a cast iron head Pontiac V8. Running aluminum heads or an aftermarket block, tell us in the notes so the spring matches the weight the car actually carries.
Not sure what your Pontiac needs?
Call our tech team at 866-762-7527. Tell us your engine, heads, car, and power goal, and we will put the parts together as one combination that works.
