428 Engine Rebuilder Assemblies
Pontiac V8 428 Engine Rebuilder Assemblies
A 428 That Stays a 428 — 428 Engine Rebuilder Assemblies for Pontiac V8s
428 Engine Rebuilder Assemblies are the shelf for a 428 that is going back in the car as a 428. The parts are Butler-selected to work together rather than gathered from three suppliers, which is what keeps a rebuild predictable instead of a series of clearance surprises.
Butler covers it with a 428 re-ring kit, complete rebuild kits in cast hypereutectic or forged pistons, and a balanced 433-440 ci rotating assembly on a 4.000" stroke with long rods, Total Seal rings and in-house balancing.
Browse 428 Engine Rebuilder Assemblies Products
Popular Brands:
More About 428 Engine Rebuilder Assemblies
1. Which kit fits the teardown
Four products, and the state of the block and pistons decides between them.
| 428 Re-Ring Kit | Rings, rod bearings, main bearings and a complete engine gasket kit. For a 428 whose bores and pistons are still in spec and only needs to be freshened up. |
| 428 Rebuild Kit, cast hypereutectic pistons | Pistons, rings, bearings and the complete gasket kit as one Butler-selected package, for a rebuild that will live on pump gas. |
| 428 Rebuild Kit, forged pistons | The same complete kit with a forged piston, when the engine is going to see more than stock use. |
| 433-440 ci balanced rotating assembly, 4.000" stroke | A new forged 4.000" crank, forged flat top Ross pistons with dish or dome available, bushed and full-float H-beam 6.700" rods, 990 wrist pins, Total Seal Classic Race rings, Federal Mogul or Clevite Performance bearings and Butler Process internal balancing. |
2. Why a 428 rebuilder assembly is 433-440 ci
This is the detail that surprises people coming from a 400. The rebuilder assembly on this page is a 4.000" stroke package, and combined with the 428's bore that puts the finished engine at 433-440 cubic inches rather than back at 428.
| The range moves with the bore | Bore options start at .030" over so the block cleans up and the rings seat within spec. Where in the 433-440 window you land depends on how much the cylinders needed. |
| Sonic check a 428 | These blocks are valuable and not endlessly reborable. Have the cylinder walls measured before choosing the bore, not after the pistons arrive. |
| Hone to the parts | Butler recommends having the pistons in hand when the cylinders are honed so piston-to-wall clearance is set off the actual pistons. |
3. Crank and balance decisions
| Cast or forged | A new cast steel crank is a sound upgrade over a 30-plus-year-old factory piece and is recommended for street engines without power adders. A 4340 forged crank costs more now and saves a second teardown if power goes up later. |
| Balancing | The rotating assembly is internally balanced in our shop, with the rods and pistons weighed and pin-fitted and the crank computer balanced to the assembly. It ships with a balance card. |
| Matching parts | Internally balanced means the flexplate or flywheel and the harmonic balancer both need to be neutral. |
If the goal is originality, the re-ring or rebuild kit keeps it simple. If the block is coming out for boring anyway, the balanced assembly settles the crank, pistons and balance work in one order.
Not sure what your Pontiac needs?
Call our tech team at 866-762-7527. Tell us your engine, heads, car, and power goal, and we will put the parts together as one combination that works.
