RPM Pontiac 4340 Forged Crankshaft, 4.000" Stroke, 3.25" Main, 421/428/455 Block,  2.200" BBC RJ

RPM-DG3-455B400C
New Pontiac Forged Crankshaft
3.25" Main Journal Size
4.000" Stroke
2.200" BBC Rod Journal
Pricing: $729.95

Qty:

Description

RPM Forged Crankshafts DG3 Deries
Designed for the serious street/strip racer
4340 forged material for strength and durability
.125" radius on all journals
Shot peened and stress relieved
All forged cranks are nitride hardened

SAE Certified 4340 forged material is used for superior strength and its proven performance in the aircraft and aerospace industries.
For increased strength these cranks are given a second heat treatment after rough finishing and then nitride hardened eliminating any
deformation after leaving the factory.

Butler Performance offers Pontiac 4340 forged cranks from top manufacturers in a variety of sizes, and include the latest in oiling technology. Forged Cranks offer a tremendous advantage in strength and durability over cast cranks. This is very inexpensive insurance to protect your engine and even if not necessary at your power level now, upgrading to a forged crank to build a solid bottom end will give you the option to safely upgrade power later.

Some cranks offer standard oiling(noted in description) while others offer Straight Shot Oiling.

Most Forged crankshafts require narrowed Performance or Race bearings because of the larger radius’s on the cranks main and rod journals. (Example FMP- M or CH series or C77 H or HN series)

Racing Parts Maximum (RPM) was established in Southern California in
1998. Regarded as an innovative pioneer, RPM has won the admiration and
confidence of many engine builders due to the premium quality and design of
our products while allowing competitive prices. The need for superior
products prompted us to increase our product lines on Crankshafts and
Connecting Rods.
