Fast Monty's Garage- Oil Pan Protection Plate for '64 through 72 GM A-Body's

Don't get stranded with a punctured or sheared oil pan and protect it with this 3/16" Steel Skid Plate.  Mike, AKA "Fast Monty", designed this oil pan protection plate for his Butler-equipped 1969 Pontiac GTO after nearly having his Canton road race pan sheared off at a gas station.  The same oil protection plate will fit 1964 through 1972 GM A-Body's (Tempest, LeMans, GTO, Malibu, Chevelle, Cutlass, 442, Skylark, El Camino).  Manufactured and drop shipped from Send Cut Send, Mike's favorite sheet metal fabricator.  Direct order links below;

Two Options:

Option 1) Oil Pan Protection plate WITHOUT Delrin Pads (No Tapped Holes)

Option 2) With tapped holes for Replaceable Delrin Pads (Left/Right Delrin plates included) Recommended for lowered A-Body's

Instructions;

Watch Mike's video for installation instructions

Required Hardware;

#6 Under Cut Socket Head Fasteners, from McMaster Carr (For Delrin Pad version only)

Quantity Four 3/8-16 (1.25" length) Grade 8 bolts with washers and lock washers.

Installation Tools;

Nut Rivet Tool and Riv Nut kit, from Amazon

Optional 1, 17/32" drill bit for 3/8-16 Nut Rivet

Option 2, find a "Christmas Tree" Stepped Drill bit with a 35/64" step.

Questions and Suggestions;

If you need the design modified slightly or have any questions, please email Mike;

 fastmontysgarage@gmail.com
