Reviving the Rocket: The Butler Performance Top End Kit for the Olds 403

The Oldsmobile 403 V8, a staple of the late-70s Trans Am and various GM cruisers, is often remembered more for its "smog-era" restrictions than its raw potential. Despite a massive 4.351-inch bore—larger than a Chevy 454—the factory 403 was choked by low compression and restrictive airflow.

The Butler Edelbrock Olds 403 Top End Power Package is the definitive solution to unlock this engine's hidden geometry, transforming it into a modern street performer capable of 400+ horsepower.



  1. Correcting the Compression Ratio

The primary weakness of the stock 403 is its abysmal compression, often lingering below 8:1 due to 83cc combustion chambers. This makes the engine "lazy" and inefficient.

Butler utilizes Edelbrock Performer RPM Aluminum Heads that can be specifically milled to reduce chamber size. This jump in compression provides an immediate increase in thermal efficiency and torque. Furthermore, the switch to aluminum allows the engine to run cooler and resist "pinging" (detonation) even on modern pump gas.

  1. High-Velocity Airflow

Factory iron heads were designed for economy, not high-RPM breathing. The Butler/Edelbrock kit replaces them with high-flow aluminum castings featuring:

  • Larger Valves: 2.09" intake and 1.66" exhaust valves.
  • Port Matching: Butler performs in-house port matching on the included Edelbrock Performer RPM Intake Manifold, ensuring the air/fuel mixture transitions from the manifold to the head without hitting restrictive "steps" or bottlenecks.
  1. The Custom Hydraulic Roller Camshaft

Oldsmobile engines are notoriously sensitive to camshaft selection. Butler eliminates the guesswork by including a custom-grind Butler/Comp Hydraulic Roller Camshaft.

  • Increased Lift: Unlike the flat-profile factory cams, the roller setup allows for more aggressive valve opening, significantly increasing power across the entire RPM range.
  • Durability: Roller lifters eliminate the "break-in" risks associated with modern low-zinc oils, providing a "set it and forget it" valvetrain.
  •
  1. Retaining the Iconic Look (Trans Am Applications)

For Trans Am owners, the biggest challenge of a high-performance intake is hood clearance. A standard Performer RPM intake is too tall for the factory Shaker scoop. Butler solves this by offering a Drop Base Shaker Assembly, allowing you to gain the power of a high-rise intake while keeping your Shaker perfectly functional and aligned.

Performance Specs Summary

Component

Butler Performance Upgrade

Cylinder Heads

Edelbrock Aluminum (Custom Milled)

Intake Manifold

Performer RPM (Port Matched)

Camshaft

Butler/Comp Custom Hydraulic Roller

Valvetrain

Performance Springs, Retainers, and Roller Lifters

Fasteners

ARP Head and Intake Bolts

By addressing the specific breathing and compression issues of the 403, this kit turns a "smog motor" into a high-torque powerhouse that stays true to its Oldsmobile heritage.
